Rhino Power Rack V3 | 41" Depth | 6-Post
ATE Rhino Power Rack V3 | 41″ Depth | 6-Post
The Rhino 6-Post Power Rack V3 is an enhanced iteration of our acclaimed 4-Post rack, engineered with two additional uprights and four extra cross-members for superior stability — an indispensable centrepiece for any dedicated lifting facility.
The expanded 6-post configuration optimises space, offering convenient plate storage and extensive attachment compatibility. Thanks to its robust geometry, it handles your heaviest lifts without requiring floor bolting. The rear extension adds depth, strength and durability, and provides exceptional storage — up to 8 weight horns, with options ranging from 13″ to 6″ in length.
For a lifetime investment in a power rack with unparalleled attachment versatility, the 6-Post is the ultimate choice — rooted in the Rhino Family DNA.
Built to Last a Lifetime
1. Durable Construction: Crafted from robust 3×3″ 11-gauge CR steel (3mm thick) with 6 post uprights, 8 cross-members and a bolt-together cage structure for exceptional toughness, finished with a 7-tank powder coating.
2. Enhanced J-Cups & Spotter Arms: 12mm steel J-cups and 12mm steel spotter arms with 5mm UHMW plastic liner on all sides, protecting your bar's knurl and finish and preventing scratches on the uprights.
3. Precision Laser-Cut Holes & Westside Spacing: Westside hole spacing maximises height adjustability and benching comfort, while 2″ squat-area spacing lets you pick the perfect squat height without jumping to rack the bar.
4. Versatile & Upgradeable: A ground-bolting option adds stability, and numerous laser-cut holes accept attachments — parallel-bar dip, lat/low row, safety straps, multi-grip pull-up bars and plate storage.
5. Two Pull-Up Bars: The 6-Post comes complete with 2 x 32mm pull-up bars, enabling pull-ups, muscle-ups and more from either end.
A Growing Rhino — Modular by Design
Like LEGO blocks, Rhino Racks are modular, sharing many parts across models for easy upgrades as your facility expands. Start with a 4-Post and add a 6-post extension kit, or start with the Rhino Squat Stand V3 and add a half-rack extension — and add attachments whenever you need them.
Various Colour Options!
Specifications:
| Tube | 3″ x 3″ 11-gauge (3mm) CR steel |
| Configuration | 6 uprights, 8 cross-members |
| J-Cups & Spotter Arms | 12mm steel, all-side UHMW protection |
| Front Hole Spacing | 2″ (westside) |
| Pull-Up Bars | 2 x 32mm |
| Dimensions (L x W x H) | 74″ x 47″ x 90″ |
| Clear Depth | 41″ + 24″ (rear extension) |
| Footprint (incl. base feet) | 77″ x 51″ |
| Plate Storage | Up to 8 weight horns (13″–6″) |
| Max Load Capacity | 454kg dynamic load |
| Net Weight | 197kg (excluding attachments) |
| Safeties | Pin or box safeties (select at checkout) |
| Finish | 7-tank powder coating |
| Colours | Red, Black, White |
| Warranty | 10-year structural |
Frequently Asked Questions:
What is the difference between the 4-Post and 6-Post Rhino Power Rack V3?
The 6-Post adds two extra uprights and four extra cross-members behind the main cage, creating a 41"+24" deep footprint. This adds rigidity, a second 32mm pull-up bar and storage for up to 8 weight horns. Choose it if you want maximum attachment versatility and plate storage in one freestanding unit.
Does the Rhino 6-Post Power Rack need to be bolted to the floor?
No. The wide 77" x 51" footprint and rear extension make it stable enough to handle heavy lifts freestanding. You can still bolt the base plates to the floor for added security if you prefer.
What is the weight capacity of the 6-Post Rhino Power Rack V3?
It is rated for a 454kg dynamic load, tested without floor bolting. Bolting the base plates down increases capacity further.
Are J-cups and spotter arms included?
Yes. The 6-Post ships with 12mm steel J-cups and 12mm steel spotter arms, both lined with 5mm UHMW plastic on all sides to protect your barbell and the uprights.
Can I upgrade my existing 4-Post rack to a 6-Post?
Yes. Rhino racks are modular and share parts across models, so a 6-post extension kit can be added to a 4-Post rack later as your facility grows.
What colours and safeties are available?
The rack comes in Red, Black or White with a 7-tank powder-coated finish, and you can choose pin safeties or box safeties at checkout.
